Fire-Lite UDACT-F User Manual

Panel Mounting
16
Document #50049 Rev.E0 1/22/01 P/N 50049:E0
CAUTION: Connecting a UDACT-F to an MS-9200 which also has an ACM, AFM or LDM Series annunciator con-
nected, will alter the assignments of the first eight yellow LEDs on the annunciator as follows:
TAB L E 2- 1 : Annunciator LED Assignments (MS-9200)
Yellow Annunciator LED
Assignment
Without UDACT-F
Assignment
With UDACT-F
1
System Trouble
(less AC loss)
System Trouble
(less AC loss)
2 Signals Silenced Signals Silenced
3Not Used
Program Mode
(panel off-normal)
4 Not Used Supervisory
5 Supervisory Bell Trouble
6 Prealarm Prealarm/Maintenance Alert
7 AC Fail Low Battery
8 Panel Trouble AC Fail
