Panel Mounting
18
Document #50049 Rev.E0 1/22/01 P/N 50049:E0
Connecting a UDACT-F to an MS-9600 which also has an ACM, AFM or LDM Series annunciator connected, will
not
alter the assignments of the first eight yellow LEDs on the annunciator.
TAB L E 2- 2 : Annunciator LED Assignments (MS-9600)
Yellow Annunciator LED
Assignment
With or Without UDACT-F
1
System Trouble
(less AC loss)
2 Signals Silenced
3
Program Mode
(panel off-normal)
4 Supervisory
5 Bell Trouble
6 Prealarm/Maintenance Alert
7 Low Battery
8AC Fail
