Reporting Formats
The reporting structure for the Ademco Contact ID format is as follows:
For general reports (alarm, trouble and supervisory), the GG and CCC fields are transmitted as 00 and 000 unless
changes to addresses 64 - 65 and 66 - 68 are made.
64 - 65 = Loop number (GG), factory default if 00
66 - 68 = Sensor number (CCC) for General Alarm, Fault or Supervisory messages - factory default is 000.
A typical printout of alarm and trouble reports in the Ademco Contact ID Reporting Structure follows:
Notes:
1.
In the sample report, SD46 refers to smoke detector at address 46 or on zone 46. Refer to the charts on the fol-
lowing page as well as “Point Assignments - MS-9200” on page 56 and “Code Wheel Matching Point Assign-
ments - MS-9200” on page 57, for further clarification
2. 18
, which is used in the reporting structure to identify the transmission as Contact ID, is not printed out in the
alarm and trouble report
3. Q
, which is the Event Qualifier for the reporting structure, is printed out in the report as an E for New Event or
R
for New Restore
TAB L E A- 3 :
Ademco Contact ID Reporting Structure
SSSS 18 QXYZ GG CCC
where
SSSS = Four digit Subscriber ID (addresses 17 - 20 and 43 - 46)
18 = Identifies transmission of Contact ID to the receiver at the Central Station
Q = Event Qualifier
E = New Event
R = New Restore
XYZ = Event code (shown in Table 3-4 on page 36 and Table 3-7 on page 39)
GG = Group number or Loop number
CCC = Zone or Sensor number
Time Date Rcvr/Line ID SSSS QXYZ GG CCCC
11:28 03/25 11 7777 E110 00 CCCC - general alarm
11:28 03/25 11 7777 E110 00 C046 - alarm SD46
11:28 03/25 11 7777 E300 00 CCCC - general trouble
11:28 03/25 11 7777 E380 00 C046 - trouble SD46
11:28 03/25 11 7777 R110 00 CCCC - general alarm restore
11:28 03/25 11 7777 R110 00 C046 - alarm SD46 restore
11:28 03/25 11 7777 R300 00 CCCC - general trouble restore
11:28 03/25 11 7777 R380 00 C046 - trouble SD46 restore
