Fire-Lite UDACT-F User Manual

Product Features
8
Document #50049 Rev.E0 1/22/01 P/N 50049:E0
FIGURE 1-1:
UDACT-F Assembly
Primary
Phone Line
Secondary
Phone Line
Modular Cables
P/N MCBL-7
(order separately)
Comm Fail Output
(power-limited)
24 VDC
(power-limited)
24 VDC power in
(use power-limited
source)
EIA-485 connector
(use power-limited
source)
Connect to
J16 on MS-9200,
using supplied
ribbon cable

Fire-Lite UDACT-F Specifications

General

Brand	Fire-Lite
Model	UDACT-F
Category	Security System
Language	English
