IMPORTANT NOTES
This fire is an Inset Live Fuel Gas Fire, providing radiant and convected warmth. It is designed to operate
on Natural Gas following factory set adjustments, (see Data Plate on appliance for gas type and pressure).
It is the LAW that all gas appliances and fittings are installed by a competent person (such as a CORGI reg-
istered fitter) and in accordance with the Gas Safety (Installation and Use) Regulations 1998, the relevant
British Standards for Installation, Codes of Practice and the Manufacturers' Instructions. The installation
shall also be carried out in accordance with the following regulations:
The Building Regulations issued by the Department of the Environment, the Building Standards (Scotland)
(Consolidation) Regulations issued by the Scottish Development Department.
Relevant British standards insofar as the relevant areas are not covered by these instructions.
Note: For Republic of Ireland, reference should be made to the relevant standards governing instal-
lation. (IS 813: 1996)
Failure to comply with these regulations could lead to prosecution and deem the warranty invalid.
This appliance must be installed in accordance with the rules in force and used only in a sufficiently venti-
lated space. A minimum of 100cm
2
(15.5 in
2
) purpose provided ventilation is required for this appliance, an
openable window or louvre is also required. To reduce the possibility of draughts entering the room via the
air vent, we recommend the use of "Black Hole" or "Vortex" type vents featuring internal baffles.
It should be noted that heaters create warm air currents. These currents move heat to wall surfaces next to
the heater. Installing the heater next to vinyl or cloth wall coverings or operating the heater where impuri-
ties in the air (such as tobacco smoke) exist, may discolour walls.
Consult ALL instructions before installation and use of this appliance.
This appliance is free from any asbestos material. Refractories and coal bed are constructed from ceramic
fibre.
1
Section Contents Page No.
1.0 Important Notes 1
2.0 Appliance Data 2
3.0 Installation Requirements 2
3.1 Room Sizing 2
4.0 Site Requirements 2
4.1 Ventilation 3
5.0 Unpacking the Appliance 4
5.1 Component Checklist 4
6.0 Appliance Installation 4
6.1 Preparing the Appliance 4
6.2 Gas Supply Routes 5
6.3 Installation Method 1 5
6.4 Installation Method 2 6
6.5 Installation Method 3 7
7.0 Gas Supply 8
8.0 Final Cavity Box Fixing
8
Section Contents Page No.
8.1 Cable Fixing 9
9.0 Fuel Bed 9
10.0 Fitting Decorative Hood/Frame 10
11.0 Testing and Commissioning 10
11.1 Operating the Appliance 10
11.2 Spark Failure 11
11.3 Setting Pressure 11
12.0 Briefing the Customer 11
13.0 Servicing 11
13.1 Cleaning the Coals 12
13.2 Servicing the Burner Tray 12
13.3 Pilot Assembly 12
13.4 Catalytic Converter 12
13.5 Testing for Firebox Leakage 13
14.0 Troubleshooting Guide 14
User Instructions
