Generation Digital Digital
Magnication 3.5x 5x
Objective lens diameter 42mm 50mm
Resolutions lines/mm 34mm 34mm
Angular eld of view 5º 4º
Video output signal standard CCIR/EIA CCIR/EIA
Camera resolution, pixel 500/582 510/492
Max detection distance 100m/110yd 140m/135yd
Diopter adjustment +/-5 +/-5
Battery type (1) CR123A (1) CR123A
IR illuminator working range 100m 100m
IR wavelength 810nm 810nm
Dimensions 6.3x3.3x3.3in 7.5x2.4x3.3in
Weight 13.4oz 14.1oz
FF18062
FF18063
