GoTo User Manual p23
English
15(b) Lateral Support
Start with all the straps connected to
the buckle as shown.
Turn the GoTo Seat over and
detach the lateral support by
turning the knob anti-clockwise.
Slide the lateral support up
and over the GoTo backrest.
Screw the knob back to the
slider component to prevent
mis-placing.
Turn the GoTo Seat over again
and rest the lateral support on
top of the GoTo.
--1#,2&#*2#0*13..-021'"#
straps as much as possible
but keep the buckle connected.
Pull one side of the plastic insert
out of the cover.
Remove the strap by feeding the
plastic buckle through the holes
and then through the upholstery.
Repeat with the other side of the
lateral support. Once removed from
the plastic lateral support, your
upholstery is ready for washing.
1
2
2
3
4
5
4
1
2
5
