Aerosol Generator FP-500S
1.0 Generator Installation guide line 24/06/2016 Michaelides Loucas
FirePro
Step 7
The aerosol generator is ready for cable connections.
Step 6
Pass the selected screws through the ( L ) bracket holes and fix them on the surface
material.
Page 10
