FirePro FP-20SE - Page 18

FirePro Systems
REV. BYDATEDESCRIPTION
Manufacturer and world wide supplier
FirePro.
Fire Extinguishing Aerosol Generators
D
C
B
A
4 3 2 1
D
C
B
A
4 3 2 1
DETAIL CABLE
+
-
X24
Earthing wire
: Earthing wire
Earthing tag
Activator Cable
Housing Part 2
Activator Cable
Housing Part 1
Thermoconector
Part 1
Cable connector
Nikel plated M16
cable gland
2 X 1mm+ earthing wire
1.0 Cable connection guide line 24/06/2016 Michaelides Loucas
Page 7
FP-20SE/T/TH, FP-40S/T, FP-80S/T,FP-100S, FP-200S,FP-500S.
