Aerosol Generator FP-500S
1.0 Generator Installation guide line 24/06/2016 Michaelides Loucas
Step 2
Take each ( L ) bracket and place it inside the ( Ring ) bracket.
FirePro
Step 3
Align each ( L ) bracket holes to the ( Ring ) bracket holes.
