Step 10
Connect earthing wire with earthing
tag
Step 11
Seal with silicone the cut shielded
cable and the entrance of the cable
into the Unit 1 (cable gland fixing
component).
FirePro
FirePro
Earthing tag
Silicone
1.0 Cable connection guide line 24/06/2016 Michaelides Loucas
Silicone
Cable gland fixing component
UNIT 1
Page 6
Earthing wire
Earthing wire
FP-20SE/T/TH, FP-40S/T, FP-80S/T,FP-100S, FP-200S,FP-500S.
