H07552 PARTS LIST
NO.
Part Number
Description
Qty.
NO.
Part Number
Description
Qty.
1
357713572
FIRMAN 439cc Dual Fuel Engine
1
73
357713552
Rubber Pad
1
2
357713501
Rubber Cap B
1
74
357713553
Battery
1
3
336713528
Flange Bolt M6×8
5
75
357713554
Battery Holder
1
4
357713573
Generator Wind Shield
1
76
336713593
Flange. Bolt M8×45
2
5
380713544
Rotor Assy
1
77
357713569
Screw&washer Assy M5×10
2
6
380713545
Stator Assy
1
78
336713578
Nut M5
3
7
380713537
Stator Cover
1
79
357713555
Bolt, Bend Hook
2
8
357713506
Generator End Cover
1
80
357713556
Battery Red Cable +
1
9
357713507
Carbon Brush Assembly
1
81
336713842
Black Boot
1
10
336713525
Carbon Brush Holder
1
82
336713693
Battery cable(Female 180mm)
1
11
336713524
Bolt &washer Assemblies
1
83
357713531
Nut M10
2
12
380713504
AVR
1
84
357713532
Isolator 2
1
13
336713519
Flange Bolt M5×16
2
85
357713533
Isolator 1
1
14
336713523
Terminal Block
1
86
357713585
Motor Mount
2
87
336713559
Flange. Bolt M8×16
4
15
336713520
Bolt M5×16
2
88
357713538
Support Leg
1
16
336713522
Ground Wire
1
89
336713557
Rubber, Support
2
17
357713509
Generator End Cover Cap
1
90
336713561
Flange Bolt M6×25
4
18
336713507
Flange Bolt M5×12
3
91
336713514
Ground Wire
1
19
380713506
Flange Bolt M6×200
4
92
336713516
External Star Washer Ø6
1
20
336713512
Lock Washer Ø6
8
93
336713601
Receptacle L14-30R
1
21
336713513
Washer Ø6
4
94
336713817
Control Module
1
22
336713577
Nut M5
2
95
375713516
Circuit Breaker Amp 31A
2
23
380713507
Side Cover Bolt M5×229
2
96
336713819
Tapping Screw St2.9×19
2
24
357713511
Lock Washer Ø5
2
97
336713820
Tapping Screw St2.9×32
1
25
380713508
Flange Bolt M10×285
1
98
336713821
Micro Switch 1
1
26
357713513
Lock Washer Ø10
1
99
336713822
Micro Switch 2
2
27
357713514
Washer Ø10
5
100
336713824
Fuel Valve
1
28
336713531
Flange Bolt M8×20
4
101
336713823
Main Regulator Assy.
1
29
357713515
Holder, Muff
1
102
336713826
LPG Inlet Cover
1
30
336713515
Flange Bolt M6×12
19
103
336713816
Screw M4×12
1
31
357713516
Muffler Fixed Plate A
1
104
336713815
Fuel Selector Switch
1
32
336713538
Screw&washer Assy M5×14
2
105
336713827
Electric Start Switch
1
33
357713517
Holder, Spark Arrester
1
106
336713828
Indicator Light
1
34
336713536
Arrester, Spark
1
107
357713586
Multi Meter
1
35
357713518
Muffler Fixed Plate B
1
108
336713574
Outlet Cover TT-30R
1
36
336713534
Nut M8
2
109
336713573
Outlet Cover L5-30R
2
37
336713509
Lock Washer Ø8
2
110
357713541
Outlet Cover 5-20R GFCI
1
38
336713533
Flat Washer Ø8
2
111
380713512
Bolt M6×22
1
39
357713520
Gskt., Ext.
1
112
380713515
Nut M6
2
40
380713538
Muff.,Assy.
1
113
336713830
Tapping Screw St4.8×20
2
114
336713569
Screw&washer Assy M4×8
10
41
357713523
Muffler Fixed Plate C
1
115
330713582
Screw&washer Assy M4×14
6
42
336713517
Nut M6
4
116
380713539
Control Panel
1
43
357713577
Air Filter Bracket
1
117
380713518
Receptacle 14-50R
1
44
357713524
Rubber Cap A
1
118
336713568
Nut M4
8
45
336713542
Grommet, Fuel Tank
4
119
357713588
5-20R Duplex GFCI
1
46
336713543
Washer Tank Buffer
4
120
336713586
Circuit Breaker Amp 30A
2
47
336713544
Flange Bolt M6×20
4
121
336713585
Circuit Breaker Amp 20A
1
48
357713578
Fuel Gauge Assy.
1
122
336713565
Screw M5×14
4
49
336713546
Screw M5×10
2
123
336713818
Charger
1
50
336713547
Fuel Gauge Display
1
124
336713583
Receptacle L5-30R
1
51
357713579
Fuel Tank Assy.
1
125
357713590
Control Box
1
52
336713806
Fuel Filter, Wire Mesh
1
126
357713545
Grommet
1
53
336713549
Fuel Cap
1
127
357713546
Sleeve
1
54
336713807
Tank Fitting With Filter
1
128
357713548
Grommet
1
55
336713540
Clamp Ø8×6
7
129
357713591
LPG Hose
1
56
357713580
Hose, Fuel 1
1
130
336713835
Metal Clamp (ø8-ø14)×b8
2
