FIRST SOLAR First Solar Series 6™ Modules | USER GUIDE 9 of 29
© FIRST SOLAR, INC. | PD-5-200-06 REV 5.0
Table 3: Series 6 Module Mechanical Specifications
A Length
FS-6XXX / FS-6XXXA 2009 mm +3/-1 mm (79.1 +0.11 / -0.04 in)
FS-6XXX-P / FS-6XXX-P
FS-6XXX-P-I / FS-6XXXA-P-I
2024 mm +3/-1 mm (79.7 +0.11/-0.04 in)
B Width
FS-6XXX / FS-6XXXA 1232 mm ± 2 mm (48.5 ± 0.08 in)
FS-6XXX-P / FS-6XXXA-P
FS-6XXX-P-I / FS-6XXXA-P-I
1245 mm ± 2 mm (49.0 ± 0.08 in)
C Height
FS-6XXX / FS-6XXXA
FS-6XXX-P / FS-6XXXA-P
49 mm ± 1 mm (1.9 ± 0.04 in)
FS-6XXX-P-I / FS-6XXXA-P-I 45.5 mm ± 1 mm (1.8 ± 0.04 in)
D
Junction Box
Lead Wire
4
FS-6XXX / FS-6XXXA
2.5 mm² (14 AWG)
720 mm (28.35 in) (+) & Bulkhead (-)
FS-6XXX-P / FS-6XXX-P
FS-6XXX-P-I / FS-6XXXA-P-I
2.5 mm² (14 AWG)
733 mm (28.86 in) (+) & Bulkhead (-)
Total Area
FS-6XXX / FS-6XXXA 2.47 m² (26.5 ft²)
FS-6XXX-P / FS-6XXXA-P
FS-6XXX-P-I / FS-6XXXA-P-I
2.52 m² (27.1 ft²)
Module Weight
5
FS-6XXX / FS-6XXXA 34.5 ± 1 kg (76 ± 2.2 lbs)
FS-6XXX-P / FS-6XXXA-P 34.9 ± 1 kg (76.9 ± 2.2 lbs)
FS-6XXX-P-I / FS-6XXXA-P-I 34.2 ± 1 kg (75.4 ± 2.2 lbs)
Fire Performance
6
FS-6XXX / FS-6XXXA
FS-6XXX-P / FS-6XXXA-P
FS-6XXX-P-I / FS-6XXXA-P-I
Type 19: Class A Spread of Flame /
Class C Burning Brand
4
Length from junction box exit to connector mating surface
5
When designing structure components for systems with mixed model types (mixed ‘-P’ and ‘-P-I’ model suffixes) the larger nominal
weight should be used to enable flexibility to utilize ‘-P’ modules universally in any array mounting position.
6
Module UL 1703 fire rating is valid only when mounted in the manner specified in this User Guide. Roof mounted fire rating is
established by assessing rack and module as a unit. External fire source resistance has not been evaluated.
