Series 6 Modules have been evaluated to operate in an ambient air temperature range of -40°C to +40°C
and have been tested to wind/snow loads as detailed in Tables 4.1 and 4.2. Test loads include a safety
factor of 1.5 above the design loads.
Series 6 Modules meet the following load ratings when mounted as specified in this User Guide and
evaluated according to the listed standard in Tables 4.1 and 4.2.
Table 4.1: Series 6 Module Load Ratings
Symmetrical
Four-point
Mount
Location
FS-6XXX
FS-6XXXA
A
Range of
400mm to 1200
mm (C/C)
400 mm
800 mm
1200 mm
± 1600 Pa
(± 33.4
lb/ft
2
)
± 2400 Pa
(± 50.1
lb/ft
2
)
± 1436 Pa
(± 30 lb/ft
2
)
± 2154 Pa
(± 45 lb/ft
2
)
± 1600 Pa
(± 33.4
lb/ft
2
)
± 2400 Pa
(± 50.1
lb/ft
2
)
Table 5.2: Series 6 Plus Module Load Ratings
Symmetrical
Four-point
Mount
Location
FS-6XXX-P
FS-6XXXA-P
A
Range of
400mm to
1200 mm (C/C)
400 mm
800 mm
1200 mm
± 1600 Pa
(± 33.4 lb/ft
2
)
± 2400 Pa
(± 50.1 lb/ft
2
)
± 1600 Pa
(± 33.4 lb/ft
2
)
± 2400 Pa
(± 50.1 lb/ft
2
)
FS-6XXX-P-I
FS-6XXXA-P-I
B
7
1200 mm (C/C)
1200 mm
± 1600 Pa
(± 33.4 lb/ft
2
)
± 2400 Pa
(± 50.1 lb/ft
2
)
± 1600 Pa
(± 33.4 lb/ft
2
)
± 2400 Pa
(± 50.1 lb/ft
2
)
C
Range of
400mm to
1000 mm (C/C)
400 mm
800 mm
+1300 Pa / -900 Pa
(+27.2 / -18.8 lb/ft
2
)
+1950 Pa / -1350 Pa
(+40.7 / -28.2 lb/ft
2
)
Symmetrically secure the module using a minimum of four frame contact points regardless if mounted with
top clamps or with SpeedSlot clamps. Other mounting solutions not discussed in this User Guide (Such as -
asymmetric mounting, higher load ratings, alternative clamp geometry, etc.) may be permitted, but require
7
FS-6XXX-P-I / FS-6XXXA-P-I Model Types are IEC 61215/IEC 61730 certified at Mounting Configuration B only when supplemented
with additional interface point(s). Consult First Solar for supplemental documentation.
