Installation instructions
Product dimensions (mm)
P120
C190
E150
C270
E210
C170T
E169T E249T
E240B
C373
E373
C450
E450/E388
E331T E381T E411T
E415H
E440T E521T
A
Overall height of curved door product 819 1207 1595 1207 1595 1425 1695 1425 1595 1695 1695 1695
A
Overall height of flat door product n/a n/a n/a n/a n/a n/a 1715 n/a n/a n/a n/a n/a
B
Overall width of product 525 525 525 525 525 635 635 635 635 635 680 790
C
Overall depth of curved door product
(excludes handle, includes evaporator)
575 575 575 575 575 715 715 715 715 715 715 715
C
Overall depth of flat door product
(excludes handle, includes evaporator)
n/a n/a n/a n/a n/a n/a 695 n/a n/a n/a n/a n/a
Cabinetry dimensions (mm) (including minimum clearances)
D
Inside height of cavity 869 1257 1645 1257 1635 1475 1735 1465 1595 1735 1735 1735
Flush with refrigerator chassis – full door rotation
E
Inside width 565 565 565 565 565 675 675 675 675 675 720 830
F
Inside depth 502 502 502 502 502 620 620 620 620 620 620 620
Flush with refrigerator door – full door rotation
G
Inside width 680 680 680 680 680 790 790 790 790 790 835 945
H
Inside depth flush to curved door 552 552 552 552 552 680 680 680 680 680 680 680
I
Inside depth flush to flat door n/a n/a n/a n/a n/a n/a 695 n/a n/a n/a n/a n/a
Flush with refrigerator door – 90° door rotation
(for full drawer/shelf access, the doors need to be open past 90°)
J
Inside width 635 635 635 635 635 745 745 745 745 745 790 900
K
Inside depth flush to curved door 552 552 552 552 552 680 680 680 680 680 680 680
L
Inside depth flush to flat door n/a n/a n/a n/a n/a n/a 695 n/a n/a n/a n/a n/a
Minimum clearances
M
Side clearance 20 20 20 20 20 20 20 20 20 20 20 20
N
Side clearance – hinge
side flush with door – full rotation
135 135 135 135 135 135 135 135 135 135 135 135
O
Side clearance – hinge
side flush with door – 90° rotation
90 90 90 90 90 90 90 90 90 90 90 90
P
Rear clearance
(including evaporator tray)
30 30 30 30 30 30 30 30 30 30 30 30
Q
Vent (above refrigerator cabinet or
around top of cupboard)
50 50 50 50 50 50 50 50 50 50 50 50
R
Door clearance – hinge side flush with
chassis – full rotation
440 440 440 440 440 520 520 520 520 520 555 645
S
Door clearance – hinge side flush with
door – full rotation
325 325 325 325 325 405 405 405 405 405 440 530
