14
The last user warning is also logged in diagnostics level d 00 which will be displayed as a number
from 01 through 10.
No taps 01
Wash level overloaded 02
Out of balance 03
Possible causes:
• The taps are not turned on.
• The inlet hoses may be kinked.
• The inlet hose filters at the tap end may be blocked.
• The inlet valve filter screens may be blocked.. The flow rate of the supply water is too slow.
• The product requires a minimum flow rate of 6 litreper minute.
• The drain hose is too low or the drain hose is pushed into the standpipe too far and the water is
siphoning out of the machine.
Possible causes:
• The product is overloaded.
• The user has selected the wrong water level for the load.
• The inner bowl assembly is jammed to the agitator with a foreign object that may be caught under
the agitator skirt.
• The spline drive and driven teeth are locked together with dirt, detergent or lint.
• The spline drive and driven teeth are damaged / broken.
Possible causes:
• Even distribution of the load.
• The feet have the rubber inserts fitted and the cabinet base is clear of the floor.
• The machine is correctly installed, level front to rear & side to side and does not rock on the floor.
• The bias spring is fitted between the top of the neck ring and the rear left hand suspension rod.
• The suspension is not catching or bouncy. If so, replace all four-suspension rods.
• The weight of the inner bowl. The balance ring and bowl base of the inner bowl contain water. The
most accurate way is to check the weight of the inner bowl.
• The holes in the inner bowl are not blocked and have been punched through
DISPLAY DESCRIPTION
01 nO tAP No taps
02 too FUL Bowl has failed to float
03 oUt oF bAL Out of balance
04 SUd LoC Suds lock
05 no hot No hot water
06 no CLd No cold water
07 too FUL Agitator not able to turn
08 Lid Loc Lid lock
09 Lid oPn Lid open
10 oUt oF bal Out of balance
