• Insert two #8 x 1" screws into the handlebar and tighten.
Hint: If the screws cannot be tightened, you have not
assembled the handlebar properly. Remove the handlebar
and refer back to Assembly steps 2 and 3.
• Next, push the handlebar forward and down to "snap" it
in place. Make sure you hear a "snap". This may take a
lot of force.
3
4
Assembly Tip
Please follow these instructions carefully to properly assemble the handlebar to the Smart Cycle
™
.
• Plug the handlebar connector into the socket in
the console.
Hint: The connector will only fit one way into the socket.
If it does not seem to fit, turn it around and try again!
• Place the handlebar, at an angle, onto the top of the post.
• Push to insert the tab on the back of the handlebar into
the slot in the console.
Handlebar
Connector
Socket
Tab
Post
1
2
TOP VIEW
