Thank you for choosing a Fishman Outboard Acoustic Preamp. Our goal is to provide
you with the finest products for amplifying your acoustic instrument - systems that
simply let you sound your best. With our long-standing commitment to quality, you can
feel confident that your Fishman gear will produce great sound and trouble-free
performance for years to come.
Please take a few minutes to read this guide and familiarize yourself with the preamp's
controls. Your satisfaction is very important to us. If you have any questions, please
contact us at
tteecchh@@ffiisshhmmaann..ccoomm
; or by telephone at
997788--998888--99666655
.
PRO-EQ II SPECIFICATIONS
Measured with all tone controls at center detent and volume at max.
Nominal Input Level: -20 dBV
Input Overload (20 Hz to 20 kHz) +8 dBV
Input Impedance: 10 MOhm
Output Impedance: Less than 3.5 kOhm
Nominal Output Level: -20 dBV with input gain control
at minimum position
-8 dBV with input gain control
at maximum position
THD: .015% at 1 kHz, -10 dBV input,
-4 dBV output
Signal to Noise Ratio: 93 dB (A weighted, -10 dBV input,
-4 dBV output)
Sub-Bass Control: 0 to +10 dB at 80 Hz
Bass Control Range: ± 11dB at 60 Hz
± 3 dB at 350 Hz
Middle Control Range: ± 8 dB at 1.25 kHz
± 3 dB bandwidth:1.5 kHz
Treble Control Range: ± 11dB at 10 kHz
± 3 dB at 2.4 kHz
Brilliance Control Range: ± 9 dB at 9 kHz
± 3 dB bandwidth: 7 kHz
Current Drain: Less than 2.6 mA
Power Supply: 9V alkaline battery
(estimated 220 hours continuous use)
Regulated 9V AC Adapter
tip = negative 9V
All specifications subject to change without notice.
2
2
Outboard Acoustic Preamps
Outboard Acoustic Preamps
15
15
User Guide
User Guide
