Fishman B User Manual

• The AMP output jack of the preamp is the power switch for the battery.
• To avoid battery drain,
do not leave the AMP jack plugged in when the unit is not
in use.
SPECIFICATIONS
SYSTEM GAIN 9dB (input to output at 1kHz)
All tone controls flat.
Maximum input voltage before clipping:
.8V P-P with all controls at full boost
MODEL G TONE CONTROLS
Treble: Boost and Cut ± 3dB at 1700 Hz
± 14dB at 20 kHz
Bass: Boost and Cut ± 3dB at 350 Hz
± 8dB at 50 Hz
Frequency Response 20 Hz to 20 kHz ±2dB All tone controls flat
MODEL B TONE CONTROLS
Treble: Boost and Cut ± 3dB at 850 Hz
± 14dB at 20 kHz
Bass: Boost and Cut ± 3dB at 350 Hz
± 8dB at 50 Hz
Frequency Response 20 Hz to 20 kHz ±2dB All tone controls flat
POWER SUPPLY 9 Volts (battery not included)
BATTERY LIFE 100 hours continuous use (Alkaline battery)
All specifications subject to change.
ACOUSTIC INSTRUMENT PREAMP
3
