Made in PRC
®
8. Turn on water & check for leaks. Once installed micro adjust the height of
the water level float if required.
HANDY HINT: Set water level approximately 30mm be
low top overflow tube.
Correct full flush is 6 litres, however older pans may require a larger
flush.
9. Re-check inlet valve height to ensure a minimum 30mm gap between the
CL mark and top overflow tube.
HANDY HINT: For areas with excessive water pressure ( above 1000 Kpa) it
is recommended to fit a pressure reduction valve to the main water line.
BOTTOM INLET VALVE
SIDE INLET VALVE
ADAPTOR PIECE
OR
