Flash DJ Series User Manual

CONTENTS
EN
PL
INTRODUCTION 3
SAFETY INFORMATION 3
PRODUCT INFORMATION 4
INSTALLATION 4
CONNECTION 5
DMX CHART 8
WARNING! Use clamp to rig the xture.
WARNING! When clamping the xture to a truss or other structure at
any other angle than with the yoke hanging vercally downwards, use two
clamps of half-coupler type. Do not use any type of clamp that does not
completely encircle the structure when fastened.
WARNING! Posion or shade the bar so that the front lens will not be
exposed to sunlight or any other strong light source from any angle - even
for a few seconds. See Figure 1. The LED STROBE lens can focused the
sun’s rays, creang a potenal re hazard and causing damage.
IMPORTANT! Do not point strong light output from other xtures at the
LED STEOBE, as intense illuminaon can damaged the display.
Figure 1.
2
Pages: 2-15
Strony: 16-29

Flash DJ Series Specifications

General

Voltage	AC100-240V, 50/60Hz
Pan Range	540°
Tilt Range	270°
Type	Moving Head
Control Protocol	DMX512
Cooling	Fan
Color Wheel	7 colors + open
