Flash DJ Series User Manual

9
32 CH
CH DATA Funcon Descripon
1 000-255 R Secon 1 Red linear dimming
2 000-255 G Secon 1 Green linear dimming
3 000-255 B Secon 1 Blue linear dimming
4 000-255 R Secon 2 Red linear dimming
5 000-255 G Secon 2 Green linear dimming
6 000-255 B Secon 2 Blue linear dimming
... ... ... ...
22 000-255 R Secon 8 Red linear dimming
23 000-255 G Secon 8 Green linear dimming
24 000-255 B Secon 8 Blue linear dimming
25 000-255 W Secon 1 White linear dimming
26 000-255 W Secon 2 White linear dimming
27 000-255 W Secon 3 White linear dimming
28 000-255 W Secon 4 White linear dimming
29 000-255 W Secon 5 White linear dimming
30 000-255 W Secon 6 White linear dimming
31 000-255 W Secon 7 White linear dimming
32 000-255 W Secon 8 White linear dimming

Flash DJ Series Specifications

General

Voltage	AC100-240V, 50/60Hz
Pan Range	540°
Tilt Range	270°
Type	Moving Head
Control Protocol	DMX512
Cooling	Fan
Color Wheel	7 colors + open
