3
Flash-Butrym Sp.j.
• Color: RGB color-mixture
• Gobo-wheel: 9 gobo + open + rainbow
• Shuttle: Flash rate: 0-10Hz
• Dimmer: 0-100% mechanic dimmer
• Maximum PAN-movement: 540
• Maximum TILT-movement: 270
• Master/ Slave activated by sound at pre-programmed function.
13 Control Channel
Accept DMX512 control channel, detail as follow:
Channel DMX-value Feature
1 - PAN 0~255 540°
2 - PAN 16 bitów
0~255 16 bit PAN
3 - TILT 0~255 270°
4 - TILT 16
bitowy
0~255 16 bit TILT
5 - speed 0~255 PAN/ TILT controllable speed with decreasing
6 - shutter
0~7 Close
8~134 100%-0% electrical dimmer
135~239 STROBE effect with increasing speed
240~255 Open
7 – LED_RED 0~255 Dimmer for RED 0~100%
8 –
LED_GREEN
0~255 Dimmer for GREEN 0~100%
9 – LED_BLUE 0~255 Dimmer for BLUE 0~100%
10 - LED macro
0~7 No function
8~21 White
22~35 Red
36~49 Green
50~63 Blue
