Bit 3=1
Bit 4=0
Bit 5=0
CENTER, or while using
analog braking tracks (see
„Braking“) pure DCC must
be switched on.
Bit 3: With Bit 3=1 RailCom***
is switched on. With Bit 3=0 it
is switched off.
Bit 4: With Bit 4=0 the
motor control characteristic
line will be calculated by
CV‘s 2, 5, 6. With Bit 4=1
the control characteristic
line set in CV‘s 67 up to 94
will be used (DCC operation
only).
Bit 5: to utilise the long
ad dres ses 128 up to 9999,
Bit 5 =1 should be set.
60
Light
dimming
accor-
ding
to the
loco
The value of this CV sets the
maximum intensity of the
front lights. 0=off up to
255=bright.
66 Speed
adjustion,
forward
0
Numerical values from 1 up
to 255 to alter the graduati-
on of the control characteri-
stic line for running forward.
Numbers larger than 128 will
increase the speed,
num-
bers lower than
128 decrea-
se. With 0, nothing more will
happen.
67
up
to
94
Modification
of the regu-
lation cha-
racteristic of
the control
unit
-
A speed value between 0
and 255 can be put into
each of the 28 CV‘s from 67
up to 94. In CV67 it’s the
lowest and CV94 it’s the
highest speed. The interme-
diate settings give the con-
trol characteristic line. It
determines how the vehicle
speed alters in relation to
the controller settings. This
control characteristic line is
active with CV29, Bit 4=1.
95
Speed adju-
stion back-
ward
0
Same as CV66, but for
backward running.
112 Configura-
tion values
(only
Motorola*)
Bit 3=0
Bit 3=0: normal ( 4 functions
for everyaddress).
Bit 3=1: the following
address will be used for 4
additional functions. There
are 8 functions availabe
now for this loco.
266
Volume
accor-
ding
to the
loco
The volume of the sounds
can be set in steps from
0=low up to 255=loud.
15
