INTRODUCTION
Generalspecication(-A.92.A.10)
67,67XL
Agitators
MODELAGITATOR
Model67
fourhorizontaljettype
Model67XL
fourhorizontaljettype
Spraybooms
2.5*cm(1in)schedule80Polypropylenepipe2.5*cm(1in)schedule40Stainlesssteelpipe*Approximate
metricequivalent
Controls
VALVE
SIZEandTYPE
AgitationValve
2.5*cm(1in)NPTquarterturnballvalve
InductionT ankSupplyValve2.5*cm(1in)NPTquarterturnballvalve
SupplyValve3.8*cm(11 /2in )NPTquarterturnballvalve
InductionT ankSuctionValve3.8*cm(11 /2in )NPTquarterturnballvalve
VenturiSupplyValve2.5*cm(1in)NPTquarterturnballvalve
WaterTransferValve5.0*cm(2in)NPTquarterturnballvalve
*Approximatemetricequivalent
Filter(Line)
3.8*cm(11/2in)NPT,80meshstrainer*Approximatemetricequivalent
Fittings
GFP(glasslledpolypropylene)
Hoses
HOSESIZE
Supply5.0*cm(2in )
Agitation
2.5*cm(1in)
ToSprayBoom2.5*cm(1in )
*Approximatemetricequivalent
Nozzles
COMPONENT
TYPE
NozzleAssemblies
Spliteyeletdiaphragmchecktype
Swivelnozzle -spliteyeletdiaphragmchecktype
NozzleCapsQuick -connectcolorcoded
NozzleTips
Awiderangeof80°or110°atfanspraytipsareavailableinTeeJet
VisiostainlesssteelorCombo-Jetstainlesssteel.
ElectricBallValves
COMPONENTDESCRIPTION
PowerRequirement12voltsdc,1amps
OperatingRange0-1034kPa(0-150psi
InletPort
5.0*cm(2in)FLANGE
OutletPort2.5*cm(1in)NFPT
*Approximatemetricequivalent
SQ-044V1212/10/2004
31
