Replacement Lead
Hose Part # Replacement Lead Hose Material, Size, & Type
L8305FZ / L8306FZ L8305FZLI Flexzilla® 3/8” x 5’ Air Hose - Lead In
L8335FZ L8335FZLI Fl
Flexzilla® 1/2” x 10’ Water Hose - Lead In
exzilla® 1/2
L8340FZ L8340FZLI
” x 5’ Air/Water Hose - Lead In
Ref.# Replacement Part# Description Needs to be replaced If...
Corresponding Model#
1a L8300-W Wall / Overhead Mounting Bracket New mounting hardware is needed All Models
1b L8300-B Bench / High Wall Mounting Bracket An alternative mount is needed All Models
2 RP005000BK Top Outer Housing Half w/ Trim Ring & Housing Clips - Black The upper housing is damaged All Models
3 RP005002BK Swivel Body Side Plate - Black The side plate is damaged All Models
All Models
All Models
All Models
All Models
All Models
4 RP005007-xx Swivel Body - Based on hose inner diameter Internal leaking See Replacement Swivel & Hose Stop Chart
5a RP005015 Internal Drum Assembly / Retraction Spring The hose does not retract the hose at all 50’ Model
5b RP005016 Internal Drum Assembly / Retraction Spring The hose does not retract the hose at all 70’ and 75’ Models
6a RP005010-14 Layering Device Assembly The layering mechanism doesn’t operate L8335FZ
6b RP005010-20 Layering Device Assembly The layering mechanism doesn’t operate L8305FZ & L8306FZ
L8305FZ & L8306FZ
7a RP005012-137 Layering Device Drive Belt The layering mechanism doesn’t operate L8335FZ
6c RP005010-18 Layering Device Assembly The layering mechanism doesn’t operate L8340FZ
7b RP005012-140 Layering Device Drive Belt The layering mechanism doesn’t operate
8a RP005004BK Latch Switch Side Plate w/ Latch Spring & Pawl Mechanism- Black The hose does not lock the desired length
7c RP005012-138 Layering Device Drive Belt The layering mechanism doesn’t operate L8340FZ
8b RP005004GRNT Latch Switch Side Plate w/ Latch Spring & Pawl Mechanism- Granite The hose does not lock the desired length
9 RP005003 Tension Cover The tension cover is cracked or damaged
10 RP005001BK Bottom Outer Housing Half w/ Housing Clips - Black The bottom housing is damaged
11 RP005018 Latch Spring & Pawl Mechanism The hose does not lock the desired length
12 Lead In Hoses Lead in or Supply Hose The hose is damaged or leaks See Replacement Lead Hose Chart
13 Hose Stoppers Hose Stop The hose stopper is not stopping the hose See Replacement Swivel & Hose Stop Chart
14 Hose Assembly Hose Assembly w/ Hose Stopper The hose is damaged or leaks See Replacement Hose Assembly Chart
Replacement Parts
Replacement Lead-In Hoses
FIVE YEAR LIMITED WARRANTY
For warranty information visit flexzilla.com/warranty or call 800-645-8258
