Flieks MF291663 - Step 2: Frame #2 Assembly; Step 3: Frame #3 Assembly

NOTE
:
In this step, DO NOT tighten any bolt until you connect all part together.
PAGE 6 OF 11
NOTE
:
In this step, DO NOT tighten any bolt until you connect all part together.
B 10PCS
1/4*15
C 4PCS
Ø42
D 1PC
4*59
C*4
2
3
5
5
1
4
4
1
B
B
C
B*10
D 1PC
4*59
B 4PCS
1/4*15
STEP 3 : Following below illustration Assembly Frame #3.
Using hardware #B connect #6, #7 with #11, #12 to complete Frame #3.
12
*
19
11
*
2
6
7
STEP 2 : Following below illustration Assembly Frame #2.Using hardware #B, #C connect #1 , #2,
#3, #4 with #5 to complete Frame #2.
B
TWIN OVER TWIN BUNK BED
ASSEMBLY INSTRUCTIONS
SKU MF291663
