FRD-100 BL Manual page 3 of 7
2. Characteristics
DISPLAY
Character Height 100 mm
Number of digits 5
Resolution 7 segments plus colon and decimal point
Technology Transflective positive TN LCD
Backlight Yes; Amber LED
MECHANICAL
Size casing 540 mm x 169 mm x 35 mm (w x h x d) (w/o connector)
Size inc. bracket 550 mm x 180 mm x 58 mm (w x h x d) (w/o connector)
Materials Stainless Steel 316
Protection IP-65
Weight 4,5 kg net
Display Dimensions
ELECTRONICS
Interface field selectable/autosearch: RS-232, RS-485 and 20 mA TTY
Current Loop
Data Format 300-38400 Baud with 7 or 8 databits even, odd or no parity
(Default: 9600, 7, Even)
Power requirements 9V DC (without backlight) - 24V DC (with backlight)
(typically power consumption <=100 mA)
Connection Unterminated 4m cable
