Remote Viewing Interface
16
5. In the video window, select the area you wish to monitor for motion.
6. Click Save to apply your settings.
Result: The system beeps when it detects motion, and a green "M" icon appears. The
green "M" icon indicates that the system is only detecting motion, but not recording. To
have the system record motion events, enable motion recording in the recording calendar
(Remote Setting tab > Record > Schedule).
16.21 Configuring Alarm Notifications
Configure the settings for alarm devices (not included).
To configure alarm notifications:
1. Click the Remote Setting tab, and click Alarm > Alarm.
2. Configure the following:
• Alarm In: Select the channel that you wish to configure.
• Alarm Type: Select the alarm type N/O (normally open), N/C (normally closed), or
select OFF.
• Buzzer: Select the "beep" duration when an event occurs.
• Latch Time: Select the desired latch time when an alarm triggers.
• Show Message: Select the checkbox so that the system displays a warning mes-
sage during an alarm recording.
• Send email: Select the checkbox for the system to send out email alerts during
alarm recording.
• Full Screen: Select the checkbox to enable the system to go into Full-screen View
when an alarm triggers.
• Alarm out: Select the checkbox to enable alarm out devices to activate.
• Enable Record: Select the checkbox to enable system recording when an alarm
triggers.
• Post Recording: Select the desired post recording time after an alarm triggers.
• Record Channel: Select the channels that the system should record during an
alarm trigger.
3. Click Save to apply your settings.
#LX400005; r. 1.0/13714/13883; en-US
91
