FLIR InfraCAM - 5 Camera Parts; Front View

5 Camera parts
5.1 Front view
Figure
10601703;a2
Explanation
This table gives an explanation to the figure above:
Laser pointer with lens cap1
Focus ring2
Infrared lens3
Lens cap for infrared lens. To prevent losing the lens cap, you can attach
it to the tripod mount.
4
5
Publ. No. 1558299 Rev. a200 – ENGLISH (EN) – February 12, 2007 11
