Flo-Tite MPF15 - Page 3

IOM-MPF15-01
Typical 3 Way MPF15 / MPF30
Item No. Part Name
1Body
2End Cap
3 Ball
4Seat
5 Cap Gasket
6 Body Nut
7 Body Stud
8 Anti-Static
9 rust Bearing
10 Stem Packing
11 Packing Follower
12 Gland
13 Gland Bolt
14 Stop Housing
15 Housing Bolt
16 Travel Stop
17 Lever Handle
18 Snap Ring
19 Cover
20 Cover Gasket
21 Cover Stud
22 Cover Nut
23 Port Sign
24 Sign Nut
25 Washer
Page 3
