D. Assembly
1.
Install
the
belt tension bar.
2. Install the metal arrester.
3. Install the eye shield.
4. Install the dust tray.
1.
Install
the
tool rest
support.
2. Install the tool rest.
3. Adjust the tool rest support by
washer to make the tool rest
parallel to the belt.
