370542 D/GB
28
GB
1. The angle of the tool rest is
designed to be adjustable according
to your working requirements.
2. The adjusting handle (parts No.42)
will serve this purpose.
3. Adjust the dust shield plate until a
slight contact is made with the tool
rest, then secure the tool rest firmly.
Replacement of the grinding belt
1. Pull the belt tension bar (part No.39)
upward till it is locked.
2. Open the belt top cover.
3. Remove the original belt by
moving out the belt of the front roller
slightly, then remove the belt of the
motor roller. Put the new belt on rollers
in reserve order. Pull down the belt
tension bar and perform a running test.
