13.0 Adjusting the drilling depth
13.1 On machines without a digital depth indication pull the limit stop (5) axially to the right, select the drilling depth
and push the limit stop (5) to the left. (s. diagram 8)
13.2 On machines with a digital depth indication place the drilling tool with the drill lever onto the workpiece. Zero
the digital depth indication (3). (s. diagram 4) Drill to the required depth which is shown digital at the frontplate. Use
the limit stop (5) as fixed stop (s. diagram 8). With fine adjustment + or – you can set the exact depth.
14.0 Pinion feed
14.1. The pinion feed is made with the lever.
15.0 Adjustment of table
15.1 On machines without a rack untension the clamping lever, position the drilling table and tension the clamping
lever. Attention! Secure the table against falling.
15.2 On machines with a rack untension the clamping lever, adjust the table height by means of the hand crank
and tension the clamping lever.
16.0 Adjustment of the return spring tension
Attention! Disconnect the machine from the electrical supply.
16.1 Remove plastic-cover. Loosen screw (9) and tension or untension the spiral spring (3) by rotating the tension
plate (2). Tighten screw (9). (s. diagram 8)
17.0 Adjustment of the speed adjustment lever brake
Attention! Disconnect the machine from the electrical supply. Adjust screw (5).Clock – wise in order to tighten
the brake. (s. diagram 7)
18.0 Height adjustment of drilling head
Attention! Squeezing danger; before adjusting the drilling head, untighten the clamping lever. After positioning
retighten again.
19.0 Tool change
For the change of drills or other clamping tools a tool drift/ejector as per DIN 317 is needed. This drift is put in the
spindle slot. Release the tool with soft hammer strokes.
Attention: Do not push the spindle to its top position while the drift is inserted in the spindle slot!
For reasons of tool protection remove it by hand, otherwise the impact on the vice or table might cause a damage.
20.0 Care reference
For cleaning each standard cleaning agent for plastic is suitable.
