11.0 Surface grinding TBSM 75 (fig.1 / 3)
Open the cover (6) and push the material hardly against the graphit grinding base (8).
The fence (3) is adjustable by loosening the clamping lever (24) up to 45°. Do not remove the cover (1) by phase -
grinding. The cover (1) is to be adjusted to the corresponding material thickness, therefore loosen the star knob nut
(23). After adjusting tighten the star knob (23).
11.1 Surface grinding BSM 75/ 150 (fig.5)
Open the cover and push the workpiece hardly against the graphit grinding base (3).
12.0 Adjusting of grinding arm TBSM 75 (fig.3)
The grinding arm is steppless adjustable in horizontal and vertical position. Loosen screws (26) with the hexagon
socket wrench, adjust the angle and tighten the screws.
13.0 Height and angle adjustment BSM 75/ 150(fig.4)
Height and angle of the machine can be adjusted to the most comfortable position by loosening the screws (19) and
retightening.
14.0 Maintenance
Ensure that all moving parts are kept clean and that the belt is in good condition. Never use a badly worn or torn
belt.
15.0 Exhausting
For continous operation a dust exhaust system is necessary!
(exhaust system capacity for TBSM 75 andBSM 75 min. 400 m³/h
exhaust system capacity for BSM 150 min. 600 m³/h).
16.0 Edges and deburring device (fig. 5)
Disassemble the grinding bearing surface (13) of BSM75/150. The edges and deburring device are fastened with
the same fastening elements (guide pin and clamping lever) of the grinding bearing surface.
You can change the land size by loosening of the clamping lever and by gradually shifting the device in the
elongated hole area from 0-45° to 4-45°.
