8) Slide either the side exit pipe #86325S or rear exit pipe #86326S onto the ends of both over
axle pipes. Place a clamp onto these slip-fit connections and tighten just enough to hold in position.
Place the two stainless tips #ST461 onto the exit pipes and tighten the pinch bolts just enough to hold
in position. Rotate the exit pipe and tip to the desired distance from the fender or bumper so that the
tips are in the desired location. The final adjustment of the tips is best left to the final step, with the
vehicle on the ground so that you can get a good view.
9) Now go back and adjust the position of all pipes and muffler to provide a satisfactory fit. A
minimum of 3/4” clearance around all parts of the system must be maintained; while keeping
suspension travel and vibration in mind. After adjustments have been made, you may now securely
tighten all clamps, including the front hanger/clamp assembly.
10) After the system is secure, slide the 7/16” hanger keeper onto the left tailpipe hangers. This
keeper will prevent the hanger rods from slipping out of the rubber mount.
PACKING LIST
Qty Description Part#
1 Inlet Pipe 26532S
1 Adapter Pipe 26277S
1 Muffler 8530452-176
1 Right Tailpipe 86327S
1 Left Tailpipe, Front 86323S
1 Left Tailpipe, Rear 86324S
2 Side Exit Pipes 86325S
2 Rear Exit Pipes 86326S
2 Stainless Tip ST461
1 Parts Kit PK800
1 Ring Clamp Hanger 490HA
1 Frame Hanger, Rear 226HA
5 2 1/2” Band Clamp MC250BS
2 3” Band Clamp MC300BS
1 Rubber Hanger HA168
1 Back-up plate HA226
2 7/16” Hanger Keeper HW502
1 3/8” x 3.50” Tap Bolt HW234
2 3/8” x 2” Bolt HW211
4 3/8” Flat Washer HW303
3 3/8” Nut HW103
3 3/8” Lock Washer HW309
Pg 3 of 4 Technical Support (707) 544-4761
