GETTING
STARTED
Setting up your
sprayer
Remove the nuts and
bolts (6), holsters (4, 5)
and nozzles (13, 14, 15)
from the tank strainer (3).
Set aside.
Bring the ComfortStraps™
(11) to the bottom of the
tank. Secure the lower
strap clips to the loops at
the bottom of the tank.
2
3
A B C
Next, slide the adjustable strap through the top tank loop.
Continue by sliding the strap under and over the buckle
tting. Lightly tug to make sure the strap is secure. Repeat on
other side.
1
NOTE: The sprayer may
have residual water in it
when rst opened. This is
due to quality testing every
sprayer undergoes before
leaving our factory.
