SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK
Ventus-2c FLIGHT MANUAL
All instruments and control elements are within easy reach of the pilot
(1) Tilt-up instrument panel
Two quick-fasteners or screws secure the glare shield to the
instrument panel and to its tubular mounting frame.
Panel rises under light pressure with the canopy opened.
(2) Ventilator control
Knurled gold-coloured knob on the cockpit inner skin on the left in
the front.
Ventilator closed : Knob in backward position
Ventilator opened : Knob in forward position
Adjustable bull-eye-type ventilator on the starbd. cockpit inner skin.
Turned clockwise : Ventilator closed
Turned anti-clockwise : Ventilator opened
Additionally the sliding window or the air scoop in the window may
be opened for ventilation.
(3) Wheel brake
The wheel brake lever is mounted on the control stick.
November 2003
Revision -- 7.2.2
