SCHEMPP-HIRTH FLUGZEUGBAU GmbH., KIRCHHEIM/TECK
Ventus-2c FLIGHT MANUAL
6.2 Weight and balance record / Permitted seat load range
The following loading chart (page 6.2.3) shows the maximum and minimum load
on the seat - with the fuel load in the fuselage already taken into account.
These charts are established with the aid of the last valid weighing report - the
required data and diagrams are found in the Maintenance Manual.
Both loading charts (weight & balance log sheets) are only applicable for this
particular sailplane, the serial number of which is shown on the title page.
A seat load of less than the required minimum is to be compensated by ballast
- there are two methods:
1. By attaching ballast (lead or sand cushion) firmly to the lap belt mounting
brackets.
2. By installing ballast (by means of lead plates) into the fuselage nose.
For further information refer to page 6.2.2.
November 2003
Revision -- 6.2.1
