11 Rev. 03
PHOENIX P30
POSITION CODE MATERIAL DESCRIZIONE DESCRIPTION Q. for PUMP
1 P0018CC000023PP PP Centrale Central block 1
1a P0030FL000029PP PP Flangia Warhead 2
2 E-018 POM-C Distributore Pneumatic Exchanger 1
3 P0030AL000089A2 AISI 304 Albero Shaft 1
3a GUARNORC00106NR NBR O-ring albero Shaft O-ring 1
5 MOLLA70C20081AC STEEL Molla a tazza Belleville washer 2
6 P0018PT005227AL ALUMINUM Piattello lato aria Air side cap 2
7a P0030ME004272HY HYTREL Membrana lato aria Air diaphragm 2
7a P0030ME004272SA SANTOPRENE Membrana lato aria Air diaphragm 2
7b P0030ME004706TF PTFE Membrana lato fluido Fluid diaphragm 2
8 P0018CA105092PP PP+VTR Cappellotto lato fluido Fluid side cap 2
8 P0018CA105092EC ECTFE Cappellotto lato fluido Fluid side cap 2
10 P0018SL000085FL FELT Silenziatore Silencer 2
11 P0030CP000017PP PP+VTR Corpo pompa Pump casing 2
11 P0030CP000017PC PP+CF Corpo pompa Pump casing 2
11 P0030CP000017PM POM+VTR Corpo pompa Pump casing 2
11 P0030CP000017OC POM+CF Corpo pompa Pump casing 2
11 P0030CP000017FC PVDF+CF Corpo pompa Pump casing 2
11 P0030CP000017A4 AISI 316 Corpo pompa Pump casing 2
12a P0030CLR00019PP PP+VTR Collettore superiore Upper manifold 1
12a P0030CLR00019PC PP+CF Collettore superiore Upper manifold 1
12a P0030CLR00019PM POM+VTR Collettore superiore Upper manifold 1
12a P0030CLR00019OC POM+CF Collettore superiore Upper manifold 1
12a P0030CLR00019FC PVDF+CF Collettore superiore Upper manifold 1
12a P0030CLR00122A4 AISI 316 Collettore superiore Upper manifold 1
12a F0030CLR00124A4 AISI 316 Collettore superiore CLAMP Upper manifold CLAMP 1
12b P0030CLR00018PP PP+VTR Collettore inferiore Lower manifold 1
12b P0030CLR00018PC PP+CF Collettore inferiore Lower manifold 1
12b P0030CLR00018PM POM+VTR Collettore inferiore Lower manifold 1
12b P0030CLR00018OC POM+CF Collettore inferiore Lower manifold 1
12b P0030CLR00018FC PVDF+CF Collettore inferiore Lower manifold 1
12b P0030CLR00123A4 AISI 316 Collettore inferiore Lower manifold 1
12b F0030CLR00125A4 AISI 316 Collettore inferiore CLAMP Lower manifold CLAMP 1
13 P0030GA000020EC ECTFE Gabbia Ball cage guide 4
13 P0030GA000020PP PP Gabbia Ball cage guide 4
14 SFERAINC11016TF PTFE Sfera Ball 4
14 SFERAINC11016A4 AISI 316 Sfera Ball 4
15a P0030SD000136PP PP Sede sfera con O-ring N° 41 Ball seat with O-ring N°41 4
15a P0030SD000136FV PVDF Sede sfera con O-ring N° 41 Ball seat with O-ring N° 41 4
15a P0030SD000136PM POM-c Sede sfera con O-ring N° 41 Ball seat with O-ring N° 41 4
15b P0030SD000090PP PP Sede sfera Ball seat 4
15b P0030SD000090FV PVDF Sede sfera Ball seat 4
15b P0030SD000090PM POM-C Sede sfera Ball seat 4
15b P0030SD000103A4 AISI 316 Sede sfera Ball seat 4
19 VITEM15C06025A2 AISI 304 Viti collettore Manifold screw 8
19b DADOM32C00006A2 AISI 304 Dadi collettore Manifold nuts 8
21 VITEM10C06140A2 AISI 304 Viti corpo pompa Casing screw 4
21a RONDP51C06018A2 AISI 304 Rondelle corpo pompa Casing washers 4
21b DADOM31C00006A2 AISI 304 Dadi corpo pompa Casing nuts 4
32 GUARNORC04118DT EPDM O-ring superiore Upper o-ring 4
32 GUARNORC04118VT FPM O-ring superiore Upper o-ring 4
32 GUARNORC04118TF PTFE O-ring superiore Upper o-ring 4
33 GUARNORC04081DT EPDM O-ring inferiore Lower o-ring 4
33 GUARNORC04081VT FPM O-ring inferiore Lower o-ring 4
33 P0030GN000092TF PTFE Guarnizione inferiore Lower gasket 4
41 GUARNORC04055DT EPDM O-ring interno sede Internal O-ring 4
41 GUARNORC04055VT FPM O-ring interno sede Internal O-ring 4
47 P0018DS000037PP PP Distanziale corsa Spacer 2
51 RACCOMMC06007OT BRASS Raccordo aria Air connection 1
