fluimac PHOENIX - Page 13

13 Rev. 03
PHOENIX P50
POS. CODE MATERIAL DESCRIZIONE DESCRIPTION
Q. for
PUMP
1
P0050CCR04804PP
PP+VTR
Semicorpo
centrale
Central half block
2
1
P0050CCR04804PC
PP+CF
Semicorpo centrale
Central half block
2
2 E-050 POM-c Distributore Pneumatic Exchanger 1
3
P0050AL004803A2
AISI 304
Albero
Shaft
1
3a
GUARNORC02050NR
NBR
O
-
ring albero
Shaft O
-
ring
1
5
MOLLA70C25122AC
STEEL
Molla a tazza
Belleville washer
2
6
P0050PT004252AL
ALUMINUM
Piattello lato aria
Air side cap
2
7a
P0050ME004793HY
Hytrel
Membrana lato aria
Air diaphragm
2
7a P0050ME004793SA Santoprene Membrana lato aria Air diaphragm 2
7b
P0050ME004794TF
PTFE
Membrana lato fluido
Fluid diaphragm
2
8
P0050CA104163PP
PP+VTR
Cappellotto lato fluido
Fluid side cap
2
8
P0050CA104163EC
ECTFE
Cappellotto lato fluido
Fluid side cap
2
8
P0050CA104163PC
PP+CF
Cappellotto lato fluido
Fluid
side cap
2
8
P0050CA004938AL
ALUMINUM
Cappellotto lato fluido
Fluid side cap
2
8 P0050CAR04441A4 AISI 316 Cappellotto lato fluido Fluid side cap 3
9
P0050TP004797PP
PP
Tappo semicentrale
Stopper central half block
1
10
P0050SL004805FL
FELT
Silenziatore
Silencer
1
11
P0050CP004801PP
PP+VTR
Corpo pompa
Pump casing
2
11
P0050CP004801FC
PVDF+CF
Corpo pompa
Pump casing
2
11
P0050CP004801PC
PP+CF
Corpo pompa
Pump casing
2
11 P0050CP004806AL ALUMINUM Corpo pompa Pump casing 2
11
P0050CPR04788A4
AISI 316
Corpo pompa
Pump casing
2
11 P0050CPR04788A4
AISI 316
POLISHED
Corpo pompa Pump casing 2
12 P0050CLR04800PP PP+VTR Collettore superiore/inferiore Upper/lower manifold 2
12
P0050CLR04800FC
PVDF+CF
Collettore
superiore/inferiore
Upper/lower manifold
2
12
P0050CLR04800PC
PP+CF
Collettore superiore/inferiore
Upper/lower manifold
2
12
P0050CLR04739AL
ALUMINUM
Collettore superiore/inferiore
Upper/lower manifold
2
12
P0050CLR04789A4
AISI 316
Collettore
superiore/inferiore
Upper/lower manifold
2
12 F0050CLR04790A4
AISI 316
POLISHED
Collettore superiore/inferiore Upper/lower manifold 2
13
P0050GA004807PP
PP+VTR
Gabbia
Ball cage guide
4
13
P0050GA004807EC
ECTFE
Gabbia
Ball cage guide
4
14
SFERAINC07008TF
PTFE
Sfera
Ball
4
14 SFERAINC07008A4 AISI 316 Sfera Ball 4
14
SFERAINC07008DT
EPDM
Sfera
Ball
4
14
SFERAINC07008NR
NBR
Sfera
Ball
4
15a P0050SD005087PP PP
Sede sfera con o
-
ring o guarnizione
N°41
Ball seat with o
-
ring
or gasket
N°41
4
15a P0050SD005087FV PVDF
Sede sfera con o
-
ring o guarnizione
N°41
Ball seat with o
-
ring or gasket
N°41
4
15b
P0050SD000119PZ
UHMW HDPE
Sede sfera
Ball seat
4
15b P0050SD004808AL ALUMINUM Sede sfera Ball seat 4
15b
P0050SD004808A2
AISI 304
Sede sfera
Ball seat
4
19
VITEM10C06045A2
AISI 304
Viti collettore
Manifold s
crew
8
19b
DADOM32C00006A2
AISI 304
Dadi collettori
Manifold n
uts
8
21
VITEM10C06075A2
AISI 304
Viti corpo pompa
Casing s
crew
12
21a
RONDP51C06018A2
AISI 304
Rondelle
Washers
20
21b DADOM31C00006A2 AISI 304 Dadi Nuts 16
22
VITEM10C06100A2
AISI 304
Viti semicentrale
Central half block s
crew
4
22a
RONDP50C06014A2
AISI 305
Rondella semicentrale
Central half block w
ashers
4
26
GUARNORC04075NR
NBR
O
-
ring
O
-
ring
.
2
28
GUARNORC03150NR
NBR
O
-
ring
O
-
ring
1
30
GUARNOMC00402NR
NBR
O
-
ring
O
-
ring
4
32 GUARNORC04143NR NBR O-ring superiore Upper o-ring 4
32
GUARNORC04143VT
FPM
O
-
ring superiore
Upper o
-
ring
4
32
GUARNORC04143DT
EPDM
O
-
ring superiore
Upper o
-
ring
4
32
P0050GN004580TF
PTFE
Guarnizione superiore
Upper g
asket
4
33
GUARNORC03106NR
NBR
O
-
ring inferiore
Lower o
-
ring
4
33
GUARNORC03106VT
FPM
O
-
ring inferiore
Lower o
-
ring
4
33 P0050GN004988TF PTFE Guarnizione inferiore Lower gasket 4
33
GUARNORC03106DT
EPDM
O
-
ring inferiore
Lower o
-
ring
4
41
GUARNORC04081NR
NBR
O
-
ring interno sede
Seat i
nternal
o
-
ring
4
41
GUARNORC04081VT
FPM
O
-
ring interno sede
Seat internal o
-
ring
4
41
P0050GN004989TF
PTFE
Guarnizione interna sede
Seat i
nternal gasket
4
41
GUARNORC04081DT
EPDM
O
-
ring interno sede
Internal O
-
ring
4
* 46 P0050AN004994A2 AISI 304 Anello di rinforzo collettore Reinforcing ring manifold 2
47
P0050DS005375PP
PP
Distanziale corsa
Spacer
2
51
P0050AA004802AL
ALUMINUM
Raccordo aria con O
-
ring
Air connection with O
-
ring
1
*ACCESSORIO/ACCESSORY
