fluimac PHOENIX - Page 26

26 Rev. 03
PHOENIX 400 PLASTIC AND
ALUMINIUM VERSION
PHOENIX P400 A B C D E H Q S T
Weight
Kg
Min/Max
Temperature
PP 454 260 562 190 265 400 104 13 87 18 -4°C/65°C
PVDF+CF 454 260 562 190 265 400 104 13 87 22 -20°C/95°C
PP+CF 454 260 562 190 265 400 104 13 87 40 -4°C/65°C
ALU 454 260 562 190 265 400 104 13 87 20 -20°C/90°C
