fluimac PHOENIX - Page 33

33 Rev. 03
PHOENIX PN700 AISI VERSION
POS. CODE MATERIAL DESCRIZIONE DESCRIPTION
Q. for
PUMP
1 P0700CCR04355PP PP Centrale Central block 1
1 P0700CCR04355PC PP+CF Centrale Central block 1
2 E-700 POM-c Distributore Pneumatic Exchanger 1
3 P0700AL004644A2 AISI Albero Shaft 1
4 P0700DF004363PM POM-c Disco intermedio con O-ring Intermediate plate with O-ring 2
5 MOLLA70C40162AC STEEL Molla a tazza Belleville washer 4
6 P0700PT004423AL ALUMINUM Piattello lato aria Air side cap 2
7a P0700ME004262HY Hytrel Membrana lato aria Air diaphragm 2
7a P0700ME004262SA Santoprene Membrana lato aria Air diaphragm 2
7b P0700ME004475TF PTFE Membrana lato fluido Fluid diaphragm 2
8 P0700CAR04447A4 AISI 316 Cappellotto lato fluido Fluid side cap 2
9 P0700GR004395PP PP+VTR Griglia silenziatore silencer grid 1
10 P0700SL004725FL FELT Silenziatore Silencer 1
11 PN700CPR00105A4 AISI 316 Corpo pompa Pump casing 2
11 PN700CPR00105A4
AISI 316
POLISHED
Corpo pompa Pump casing 2
12a PN700CLR00107A4 AISI 316 Collettore superiore AISI Upper AISI manifold 1
12a FN700CLR00110A4
AISI 316
POLISHED
Collettore superiore AISI
CLAMP
Upper AISI CLAMP manifold 1
12b PN700CLR00108A4 AISI 316 Collettore inferiore AISI Lower manifold AISI 1
12b FN700CLR00109A4
AISI 316
POLISHED
Collettore inferiore AISI
CLAMP
Lower AISI CLAMP manifold 1
14 SFERAMMC00060TF PTFE Sfera Ball 4
14 SFERAMMC00060A4 AISI Sfera Ball 4
15 PN700SD000138A4 AISI Sede sfera Ball seat 4
19 VITEM10C08040A2 AISI Viti collettore Manifod crew 16
21 VITEM10C08060A2 AISI Viti corpo pompa Casing screw 20
21a RONDP50C08018A2 AISI Rondelle Washers 36
21b DADOM31C00008A2 AISI Dadi Nuts 36
22 VITEA18C04018A2 AISI Viti disco intermedio Intermediate plate screw 8
23 VITEA18C04030A2 AISI Viti griglia silenziatore silencer grid screw 5
24 VITEA18C04010A2 AISI Vite tapo distributore
Cover pneumatic exchanger
screw
1
32 GUARNORC00206TF NBR O-ring sup. Upper o-ring 4
42 P0700BC004645PM POM-c Boccola con O-ring Bushing with O-ring 1
43 SEEGEFOC06525AC STEEL Seeger distributore Pneumatic exchanger seeger 1
45 P0065TP004703PP PP+VTR Tappo distributore Pneumatic exchanger cover 1
45a P0700AD004740PP PP Adattatore tappo distributore
Pneumatic exchanger
cover
adapter
1
47 P0700DS000034PP PP Distanziale corsa Stroke spacer 2
48 TUBOAIRC06170PU Poliuretano Tubo aria D 6mm Air tube D 6mm 2
49 RACCO92C00006OT BRASS Raccordo a cartuccia Fitting cartridge 4
