fluimac PHOENIX - Page 6

6 Rev. 03
PHOENIX P07
PHOENIX P07 A B C D E G H Q R S T V
Weight
Kg
Min/Max
Temperature
PP 129 65 112 54 96 102 86 18 5.5 5.5 14 57 0.7 -4°C/65°C
PVDF+CF 129 65 112 54 96 102 86 18 5.5 5.5 14 57 0.9 -20°C/95°C
POMc 129 65 112 54 96 102 86 18 5.5 5.5 14 57 0.9 -5°C/80°C
PP+CF 129 65 112 54 96 102 86 18 5.5 5.5 14 57 0.8 -4°C/65°C
