PHOENIX P18
POSITION CODE MATERIAL DESCRIZIONE DESCRIPTION Q. for PUMP
1 P0018CC000023PP PP Centrale Central block 1
1a P0018FL000024PP PP Testata Warhead 2
2 E-018 POM-C Distributore pneumatico E 007 Pneumatic Exchanger 1
3 P0018AL005220A2 AISI304 Albero Shaft 1
3a GUARNORC00106NR NBR O-ring albero Shaft O-ring 1
5 MOLLA70C20081AC STEEL Molla a tazza Belleville washer 2
6 P0018PT005227AL ALUMINUM Piattello lato aria Air side cap 2
7a P0018ME005228NR NBR Membrana NBR lato aria Air diaphragm 2
7b P0018ME005229TF PTFE Membrana PTFE lato fluido Fluid diaphragm 2
8 P0018CA105092PP PP+VTR Cappellotto lato fluido Fluid side cap 2
8 P0018CA105092EC ECTFE Cappellotto lato fluido Fluid side cap 2
10 P0018SL000085FL FELT Silenziatore Silencer 2
11 P0018CP005088PP PP+VTR Corpo pompa Pump casing 2
11 P0018CP005088PC PP+CF Corpo pompa Pump casing 2
11 P0018CP005088PM POM+VTR Corpo pompa Pump casing 2
11 P0018CP005088OC POM+CF Corpo pompa Pump casing 2
11 P0018CP005088FC PVDF+CF Corpo pompa Pump casing 2
11 P0018CP005088A4 AISI 316 Corpo pompa Pump casing 2
12a P0018CLR05089PP PP+VTR Collettore superiore Upper manifold 1
12a P0018CLR05089PC PP+CF Collettore superiore Upper manifold 1
12a P0018CLR05089PM POM+VTR Collettore superiore Upper manifold 1
12a P0018CLR05089OC POM+CF Collettore superiore Upper manifold 1
12a P0018CLR05089FC PVDF+CF Collettore superiore Upper manifold 1
12a P0018CLR05242A4 AISI 316 Collettore superiore Upper manifold 1
12a F0018CLR05263A4 AISI 316 POLISCHED Collettore superiore CLAMP Upper manifold CLAMP 1
12b P0018CLR05090PP PP+VTR Collettore inferiore Lower manifold 1
12b P0018CLR05090PC PP+CF Collettore inferiore Lower manifold 1
12b P0018CLR05090PM POM+VTR Collettore inferiore Lower manifold 1
12b P0018CLR05090OC POM+CF Collettore inferiore Lower manifold 1
12b P0018CLR05090FC PVDF+CF Collettore inferiore Lower manifold 1
12b P0018CLR05243A4 AISI 316 Collettore inferiore Lower manifold 1
12b F0018CLR05263A4 AISI 316 POLISCHED Collettore inferiore CLAMP Lower manifold CLAMP 1
13 P0018GA005091EC ECTFE Gabbia guida sfera Ball cage guide 4
14 SFERAINC00012TF PTFE Sfera Ball 4
14 SFERAINC00012A4 AISI 316 Sfera Ball 4
15a P0018SD005224PP PP Sede sfera Ball seat 4
15a P0018SD005224FV PVDF Sede sfera Ball seat 4
15a P0018SD005224PM POM-C Sede sfera Ball seat 4
15b P0018SD000089A4 AISI 316 Sede sfera Ball seat 4
19 VITEM15C06025A2 AISI 304 Viti collettore Manifold screw 8
19b DADOM32C00006A2 AISI 304 Dadi collettore Manifold nuts 8
21 VITEM10C06120A2 AISI 304 Viti corpo pompa Casing screw 4
21a RONDP51C06018A2 AISI 304 Rondelle corpo pompa Casing washers 4
21b DADOM31C00006A2 AISI 304 Dadi corpo pompa Casing nuts 4
32 GUARNORC04093DT EPDM O-ring superiore Upper o-ring 4
32 GUARNORC04093VT FPM O-ring superiore Upper o-ring 4
32 GUARNORC04093TF PTFE O-ring superiore Upper o-ring 4
33 GUARNORC00119DT EPDM O-ring inferiore Lower o-ring 4
33 GUARNORC00119VT FPM O-ring inferiore Lower o-ring 4
33 P0018GN000086TF PTFE Guarnizione inferiore Lower gasket 4
41 GUARNORC03043DT EPDM O-ring interno sede Seat internal O-ring 4
41 GUARNORC03043VT FPM O-ring interno sede Seat internal O-ring 4
41 P0018GN000087TF PTFE Guarnizione interna sede Seat internal gasket 4
47 P0018DS000037PP PP Distanziale Spacer 2
51 RACCOMMC06007OT BRASS Raccordo aria Air connection 1
