5100 Series
NOTE
The instrument
status
might
drop
from
OPR
to STDBY
with
the change
in state
of
the
selected output.
Refer to
Table
2-
U
for
a
list
of
the operational status requiring a
change
in status.
2-104.
SELECT A STEP
—
STORE MODE
{STORAGE ONLY)
2-105.
Use the following procedure to select a pre-
determined step while in the Store Mode:
1. Select the store mode with the STORE switch.
2.
The STORE indicator illuminates.
3. Select the
number
of the
desired
step
with
the
numeric switches in the
data
entry
group.
4.
The number entered appears on the Central
Display.
5. Depress
the
SEL/ DISPLAY
STEP switch.
6. The memory
moves to the step location selected,
provided
it is within the existing program.
If not,
it steps to the
first location available for
data
entry. The
selected step number
is flashed on the
Central Display for
approximately
one
second,
then the output returns
to
its original
state.
2-106.
READ OUTPUT STATE (STORAGE ONLY)
2-107.
Read an output state previously stored in
memory using
the following procedure:
1.
Perform the select a step
(Read Mode)
pro-
cedure previously described, using the number
of the step to be read.
2. Depress
the ADVANCE/
LOAD switch.
3. The state
is transferred
to the output of the
instrument
and its
appropriate
step number is
displayed
for approximately one second, follow-
ed by the
display
of
the output condition.
2-108.
STORAGE
OUTPUT
STATE
(STORAGE
ONLY)
2-109.
Store an output state in memory using the
following procedure:
I.
Select
the store mode with the STORE switch.
2.
The STORE indicator illuminates.
3.
Verify
the state to be stored has been program-
med
into the instrument.
NOTE
The desired
slate can
be
programmed
into the
instrument at this time
or
at any time
prior
to selecting the storage mode
of
operation.
4.
Depress the
ADVANCE/LOAD
switch.
5. The
number
of the next
step
in sequence flashes
on the
Central Display
for approximately one
second, then the
display
returns to its previous
state. “End P” is displayed
if the step stored fills
the memory.
NOTE
“FULL" is displayed when the memory is
full
and
the step cannot be loaded.
2-1
10.
DELETE
INSTRUCTION
(STORAGE
ONLY)
2-1
1 i . Use thefollowing procedure
to delete a previous-
ly
entered instruction:
1.
Perform the Select a Step (store mode) proce-
dure
previously described using the number of
the
step to be deleted.
NOTE
Instrument
must be in
the Store Mode.
2.
Depress the DELETE switch.
3.
The step number deleted flashes on the Central
Display
for approximately one second. All
subsequent
steps
move up one number and the
step moved into
the
step
just deleted is tra refer-
red to the output.
2-112.
TRANSFER STORAGE MEMORY
TO
TAPE
(STORAGE ONLY)
2-1
1
3.
Transfer
the instructions stored in memory to
a
tape for
a permanent record using the following
pro-
cedure:
1.
Insure
a tape cassette is loaded in the Tape
Reader then select the Tape Mode with the
TAPE
switch.
2. The TAPE
indicator
illuminates.
2-25
