Parts
Table 4-1 lists the replaceable parts for the 8845A and 8846A Digital Multimeters. Figure
4-1 identifies the parts within the Meter.
Table 4-1. Replaceable Parts
Ref.
Desig.
Description Part
Number
Qty
8846A-4001,MAIN PCA* 2456914 1 A1
8845A-4001,MAIN PCA* 2165053 1
A1F1 FUSE 11A. 1000v, FAST .406” X 1.5” 803293 1
A1F2 FUSE 440A, 1000V, FAST .406” X 1.5” 943121 1
8846A-4002,PCA, DISPLAY/KEYBOARD 2454039 1 A2
8845A-4002,PCA, DISPLAY/KEYBOARD 2430557 1
FUSE, 0.25A, 250V,SLOW .25” X 1.25” (for 100 to 120 VAC mains power) 166306 1 F1
FUSE, 0.125, 250V, SLOW .25” X 1.25” (for 200 to 240 VAC mains power) 166488
H1 SCREW,SCREW,FHU,P,LOCK,MAG SS,6-32,.250 320093 9
H2 SCREW,8-32,.250,PAN,PHILLIPS,STEEL,ZINC-CLEAR,LOCK 228890 2
H3 SCREW,SCREW,WH,P,THD FORM,STL,5-20,.312 494641 5
H4 SCREW,6-32,.250,PAN,PHILLIPS,STEEL,ZINC-CLEAR,LOCK 152140 4
H5 SCREW,SCREW,FH,P,LOCK,STL,8-32,.312 281725 2
H6 NUT,NUT,HEX,STL,8-32 110544 1
H7
CONNECTOR,TERMINAL BLOCK,PLUGGABLE,3.5MM CTR,RT ANG,3
POS,BULK 2434588
1
H8
CONNECTOR ACCESSORY,MICRO-RIBBON,SCREW LOCK,M3.5,6-
32,STEEL,BLACK ZINC 854737
2
H9
CONNECTOR ACCESSORY,D-SUB JACK SCREW,4-40,.250 L,W/FLAT
WASHER 1777348
2
H10 NUT,NUT,EXT LOCK,STL,8-32 195263 1
H11
SCREW,4-24,.250,PAN,PHILLIPS,STEEL,ZINC-CLEAR,TYPE B THD
FORM 1626602
1
H12 SCREW,6-32,1.000,PAN,PHILLIPS,STEEL,ZINC-CLEAR,LOCK 114215 1
H13
SCREW,6-32,.250,PAN,SLOT/PHILLIPS COMBO,STEEL,ZINC-
CHROMATE 855192
1
MP1 8845A-2020, FUSE DOOR 2439239 1
MP2 8845A-2001,TOP COVER 2439097 1
