Flux Reference Series - Product Features Overview; Reference Series Features (RC 361); Maestro Series Features (MC Comp 361)

Passive Crossover
FEATURES AND CONTENTS
Product Features
- Reference Series (RC 361)
FLUX T 160 R3 • 6.5” midwoofer, 4 layer (paper+glass fi ber+silk+ceramic) cone
• 37mm v/c with 90mm magnet diameter
• Aluminium die cast basket, vented basket
• copper reverse dust cap
FLUX M 80 R • 3” midrange, 4 layer (paper+glass fi ber+silk+ceramic) cone
• 25mm v/c with vented basket, neodymium magnet
• Copper reverse phase plug
• Aluminium die cast basket, screw connector
FLUX HT 28 R • 28mm v/c with special hand coated silk dome
• Duralium housing, screw connector
• Vented magnet with additional rear chamber
FLUX XR 361 • 3 way passive crossover for RC 361
• Real 24 KT gold plated
• Selectable input for single/dual/triple amplifi ers
• Double sided PCB with 2 OZ copper thickness to maximize signal transfers
• Using selected silver solder to maximize contacts
• Selected component to maximize each frequency characteristic to
achieve the best tonal accuracy
FLUX T 160 MC3 • 6.5” midwoofer, triple sandwich (paper+glass fi ber+silk) cone
• 37mm v/c with 90mm magnet diameter
• Auminium die cast basket, vented basket
• Aluminum reverse dust cap
FLUX M 80 MC • 3” midrange, triple sandwich (paper+glass fi ber+silk) cone
• 25mm v/c with vented basket, neodymium magnet
• Duralium reverse phase plug
• Aluminium die cast basket, screw connector
FLUX HT 25 MC • 27 mm v/c with special hand coated silk dome
• Duralium housing, screw connector
• Vented magnet with additional rear chamber
FLUX XMC 361 • 3 way passive crossover for RC 361 comp
• Real 24 KT gold plated
• Selectable input for single/dual/triple amplifi ers
• Double sided PCB with 2 OZ copper thickness to maximize signal transfers
• Using selected silver solder to maximize contacts
• Selected component to maximize each frequency characteristic to achieve
the best tonal accuracy
- Maestro Competition Series (MC Comp 361)
2
