Flux Reference Series - Installation with 3 Amplifiers

Selector A
3 Amp
Input Jumper Positions
On
Off
On
Off
Selector B
3 Amp
Input Jumper Positions
On
Off
On
Off
Input
Selector A
Input
Selector B
WARNING
Install 2 (two) Amplifi er or more, jumper input must be installed correctly.
Wrong installation on input jumper can damage the Amplifi er
Installation Using 3 Amplifi er
HT 28R
T 160 R3
M 80 R
+ -
+ -
+ -
+ -
+ -
+ -
XR 361
Reference Series [RC 361]
7
Midrange
Amplifi er
Woofer
Amplifi er
Tweeter
Amplifi er
