Follow below settings and press ‘start’ button to active RX measurement. Due to the System
simulator (8960) downlink Cell power is －70dbm,The Ant power reported from the mobile should
be about －70dbm, tolerance+-5dB. Otherwise it means there is some defect with RX path. Please
Check the GSM RX SAW and the surrounding circuit, like ASM and RF test connector.
For DCS/PCS band, do the same operation except for the band select and the 8960 band settings.
Note that the ARFCN should be the same setting as the 8960 Broadcast chan.
